WSM Series Spring Steel Retaining Ring External Easy Installation / Removal

Large Image : WSM Series Spring Steel Retaining Ring External Easy Installation / Removal

Product Details:

Place of Origin:	China
Brand Name:	lisprings
Certification:	ISO9001 TS16949
Model Number:	WZM

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Bulk packaged or Customize
Delivery Time:	7 work days
Supply Ability:	10000000

Contact Now

Detailed Product Description

Name:	Heavy Duty External Inch Spiral Retaining Rings	Size:	5mm-1000mm
Tooling Charge:	Free	Used For:	Industry
Material:	Carbon Steel Or Stainless Steel	Stock:	More Than 2000 Types
High Light:	internal retaining snap ring , spiral external retaining rings

Carbon Steel Heavy Duty Spiral Retaining Ring WZm Series External Inch

Description:

The WZM Series Retaining Ring is designed for the toughest retaining ring jobs. WZM series retaining rings use standard industry groove dimensions and are interchangeable with many stamped retaining rings. This series should be specified for thrust loads that demand deep groove, heavy section capacity.

Materials Available

1. Stainless Steel: SS201, SS303, SS304, SS316, SS416, SS420,A2

2. Steel:C45(K1045), C46(K1046),C20,1210,1018

3. Brass:C36000 ( C26800), C37700 ( HPb59), C38500( HPb58), C27200(CuZn37), C28000(CuZn40)

4, Bronze: C51000, C52100, C54400, etc

5. Iron: 1213, 12L14,1215

6. Aluminum: Al6061, Al6063

7.Plastic :ABS,PP,Nylon,POM,G10,PEEK,PVC ect .

8.OEM according to your request

Surface Finish

1, Coating :nickel , zinc,chrome,Dacromet,teflon,silver ,gold etc.

2,Anodized : any color , can according the Panton card .

3,Sand blast,Powder coating

4,Painting

5,Laser marking,printing .

Application:

Electronic products, Children’s toys, Locks, Watches, Glasses, Baby Carrie , Bicycle, Kitchen appliances, Cameras, Printers, Office equipment, Precision equipment and various kinds of vehicles

Specifications:

Part Number	Shaft Diameter(in)	Inside Diameter(in)	Radial Wall(in)	Thickness(in)	Groove Diameter(in)	Groove Width(in)	Groove Yield(lb)	Ring Shear (lb)
WZT-46	0.469	0.436	0.045	0.025	0.443	0.029	430	1800
WZT-50	0.5	0.469	0.045	0.035	0.474	0.039	460	2530
WZT-55	0.551	0.518	0.045	0.035	0.524	0.039	550	2790
WZT-56	0.562	0.529	0.045	0.035	0.535	0.039	560	2840
WZT-59	0.594	0.559	0.045	0.035	0.565	0.039	630	3000
WZT-62	0.625	0.59	0.055	0.035	0.596	0.039	660	3160
WZT-66	0.669	0.63	0.055	0.035	0.638	0.039	760	3380
WZT-68	0.688	0.648	0.065	0.042	0.655	0.046	830	4180
WZT-75	0.75	0.708	0.065	0.042	0.715	0.046	950	4550
WZT-78	0.781	0.738	0.065	0.042	0.745	0.046	990	4740
WZT-81	0.812	0.768	0.065	0.042	0.776	0.046	1030	4930
WZT-87	0.875	0.827	0.075	0.042	0.835	0.046	1240	5310
WZT-93	0.938	0.886	0.075	0.042	0.894	0.046	1460	5690
WZT-98	0.984	0.934	0.075	0.042	0.94	0.046	1530	5970
WZT-100	1	0.947	0.075	0.042	0.955	0.046	1630	6070
WZT-102	1.023	0.969	0.075	0.042	0.977	0.046	1660	6210
WZT-106	1.062	1.005	0.088	0.05	1.015	0.056	1800	7010
WZT-112	1.125	1.064	0.088	0.05	1.075	0.056	1990	7420
WZT-118	1.188	1.126	0.088	0.05	1.135	0.056	2270	7370
WZT-125	1.25	1.184	0.093	0.05	1.195	0.056	2470	8250
WZT-131	1.312	1.24	0.098	0.05	1.25	0.056	2880	8660
WZT-137	1.375	1.298	0.103	0.05	1.31	0.056	3210	9070
WZT-143	1.438	1.359	0.103	0.05	1.37	0.056	3460	9490
WZT-150	1.5	1.419	0.103	0.05	1.43	0.056	3710	9900
WZT-156	1.562	1.476	0.113	0.062	1.49	0.068	3980	12780
WZT-162	1.625	1.537	0.118	0.062	1.55	0.068	4370	13290
WZT-168	1.687	1.598	0.118	0.062	1.61	0.068	4650	13800
WZT-175	1.75	1.657	0.118	0.062	1.67	0.068	4950	14320
WZT-177	1.771	1.676	0.123	0.062	1.689	0.068	5130	14490
WZT-181	1.812	1.714	0.123	0.062	1.73	0.068	5250	14820
WZT-187	1.875	1.774	0.123	0.062	1.79	0.068	5700	15340
WZT-196	1.969	1.864	0.123	0.062	1.879	0.068	6260	16110
WZT-200	2	1.894	0.128	0.062	1.91	0.068	6360	16360
WZT-206	2.062	1.955	0.141	0.078	1.97	0.086	6710	21220
WZT-212	2.125	2.012	0.141	0.078	2.027	0.086	7360	21870
WZT-215	2.156	2.041	0.141	0.078	2.057	0.086	7620	22190
WZT-225	2.25	2.129	0.141	0.078	2.145	0.086	8430	23160
WZT-231	2.312	2.188	0.141	0.078	2.205	0.086	8830	23800
WZT-237	2.375	2.248	0.141	0.078	2.265	0.086	9230	24440
WZT-243	2.437	2.307	0.141	0.078	2.325	0.086	9650	25080
WZT-250	2.5	2.366	0.188	0.078	2.385	0.086	10250	25730
WZT-255	2.559	2.424	0.188	0.078	2.443	0.086	10490	26340
WZT-262	2.625	2.485	0.188	0.078	2.505	0.086	11130	27020
WZT-268	2.687	2.545	0.188	0.078	2.565	0.086	11590	27660
WZT-275	2.75	2.604	0.188	0.093	2.625	0.103	12250	32140
WZT-287	2.875	2.722	0.188	0.093	2.742	0.103	13620	33600
WZT-293	2.937	2.78	0.188	0.093	2.801	0.103	14120	34320
WZT-300	3	2.838	0.188	0.093	2.86	0.103	14840	35060
WZT-306	3.062	2.897	0.188	0.093	2.92	0.103	15370	35790
WZT-312	3.125	2.957	0.188	0.093	2.98	0.103	16130	36520
WZT-315	3.156	2.986	0.188	0.093	3.01	0.103	16290	36880
WZT-325	3.25	3.075	0.188	0.093	3.1	0.103	17230	37980
WZT-334	3.344	3.164	0.188	0.093	3.19	0.103	18200	39080
WZT-343	3.437	3.254	0.188	0.093	3.28	0.103	19190	40170
WZT-350	3.5	3.315	0.25	0.111	3.34	0.12	19790	48820
WZT-354	3.543	3.356	0.25	0.111	3.381	0.12	20290	49420
WZT-362	3.625	3.433	0.25	0.111	3.458	0.12	21520	50560
WZT-368	3.687	3.49	0.25	0.111	3.517	0.12	22150	51430
WZT-375	3.75	3.55	0.25	0.111	3.577	0.12	23060	52310
WZT-387	3.875	3.67	0.25	0.111	3.696	0.12	24650	54050
WZT-393	3.938	3.73	0.25	0.111	3.756	0.12	25330	54930
WZT-400	4	3.787	0.25	0.111	3.815	0.12	26300	55800
WZT-425	4.25	4.032	0.25	0.111	4.065	0.12	27940	59280
WZT-437	4.375	4.162	0.25	0.111	4.19	0.12	28760	61030
WZT-450	4.5	4.28	0.25	0.111	4.31	0.12	30220	62770
WZT-475	4.75	4.515	0.25	0.111	4.55	0.12	33580	66260
WZT-500	5	4.755	0.25	0.111	4.79	0.12	37110	69740
WZT-525	5.25	4.995	0.375	0.127	5.03	0.139	40820	83790
WZT-550	5.5	5.229	0.375	0.127	5.265	0.139	45880	87780
WZT-575	5.75	5.466	0.375	0.127	5.505	0.139	49990	91770
WZT-600	6	5.705	0.375	0.127	5.745	0.139	54290	95760
WZT-625	6.25	5.942	0.312	0.165	5.985	0.174	58760	129590
WZT-650	6.5	6.182	0.312	0.165	6.225	0.174	63410	134780
WZT-675	6.75	6.42	0.312	0.165	6.465	0.174	68230	139960
WZT-700	7	6.658	0.312	0.165	6.705	0.174	73230	145140
WZT-725	7.25	6.894	0.312	0.165	6.942	0.174	78290	172190
WZT-750	7.5	7.13	0.375	0.189	7.18	0.209	84820	178130
WZT-775	7.75	7.368	0.375	0.189	7.42	0.209	90390	184070
WZT-800	8	7.607	0.375	0.189	7.66	0.209	96130	190000
WZT-825	8.25	7.845	0.375	0.189	7.9	0.209	102050	195940
WZT-850	8.5	8.083	0.375	0.189	8.14	0.209	108150	201880
WZT-875	8.75	8.321	0.375	0.189	8.383	0.209	113800	207820
WZT-900	9	8.56	0.375	0.189	8.62	0.209	120870	213750
WZT-925	9.25	8.798	0.375	0.189	8.86	0.209	127500	219690
WZT-950	9.5	9.036	0.375	0.189	9.1	0.209	134300	225630
WZT-975	9.75	9.273	0.375	0.189	9.338	0.209	141970	231570
WZT-1000	10	9.508	0.375	0.189	9.575	0.209	150560	237500
